What is the maximum distance of single mode fiber?
Knowledge Base + 2023.12.08

The maximum distance of single mode fiber can vary depending on the specific type and quality of the fiber, as well as factors such as the signal strength and transmission equipment used. However, in general, single mode fiber is capable of transmitting data over much longer distances than multi-mode fiber. It is not uncommon for single mode fiber to support distances of up to 100 kilometers (km) or more without the need for signal regeneration. With advanced technology and optimized systems, some single mode fiber installations have achieved transmission distances of several hundred kilometers or even thousands of kilometers for specialized applications.

What is Single Mode used for?

Single Mode is used to send signals at great distances – up to 100km until the signal needs to be re-amplified.

This makes it ideal in WAN applications that require a signal to go further distances with higher payloads than other mediums can manage.

What is the advantage of using single mode fiber over multimode fiber?

Single Mode Fiber offers far less signal attenuation over distance – this alone allows it to carry data much further, and potentially at greater quantities.

The different types of fiber optic cables

There are 7 different types of Fiber cable. OS1 and OS2 are both types of Single Mode Fiber. OM cables are Multi Mode, and are OM1, OM2, OM3, OM4, and OM5, respectively.

The two types of Single Mode Fiber Optics

  • OS1 is typically used for indoor applications – where you might be connecting two buildings in a campus, for instance. It has a maximum effective distance of 10km, and speeds ranging from 1 Gbps to 10 Gbps depending on cable length.

  • OS2, in contrast, is used for outdoor applications, where distances further than OS1 can manage are needed. OS2 Fiber cables can reach up to 200 kilometers in length, and carry data loads of up to 100Gbps depending on length.

What does OS in Fiber Optic patch cables stand for?

The OS designation denotes a Single Mode core intended for long distances. This single mode of light has no other light to compete with as it travels – which means it faces little signal attenuation and can travel much farther.

What does OM in Fiber Optic cables stand for?

The OM designation tells us that the cable is a Multi Mode core used for shorter distances.

Multiple modes of light traveling down the same core ensures there is a non-trivial amount of noise that can bleed between signals. This limits the range and data rates of a Multi Mode Cable.

What is the difference between OM and OS fiber?

The OS and OM Fiber designations simply tell us what kind of core the cable is using. OS stands for Optical Singlemode – a Single Mode core used for long distances.

OM, conversely, stands for Optical Multimode – a Multi Mode core intended for shorter distances.

Singlemode vs Multimode: Which Fiber Optic patch cable should I use in my rack?

Single Mode and Multi Mode Fiber technologies have completely revolutionized the world’s capability for communication.

Which Cable type you should use depends entirely on your needs and your budget, but if you need high-throughput communication, Fiber is certainly worth checking out!
