What is the difference between QSFP and SFP?
Knowledge Base + 2023.12.01

QSFP (Quad Small Form-factor Pluggable) and SFP (Small Form-factor Pluggable) are both types of optical transceivers used in high-speed data communications, but they differ in terms of their size, speed, and applications.

1. Size: - QSFP transceivers are larger than SFP transceivers. QSFP modules are about four times the size of SFP modules, allowing them to accommodate more transceiver elements in a single module.

2. Speed and Capacity: - QSFP transceivers support higher data rates and capacity compared to SFP transceivers. QSFP modules are designed to support data rates of up to 40Gbps, 100Gbps, and even 400Gbps, while SFP transceivers typically support data rates of up to 10Gbps.

3. Applications: - QSFP transceivers are commonly used in high-speed networking equipment, such as switches, routers, and data center applications, where high bandwidth and scalability are required. SFP transceivers are used in a wider range of applications, including Ethernet, Fibre Channel, and SONET/SDH networks, where lower data rates are sufficient.

In summary, the main differences between QSFP and SFP transceivers are their size, speed, and applications. QSFP transceivers are larger, support higher data rates, and are typically used in high-speed networking equipment, while SFP transceivers are smaller, support lower data rates, and have a wider range of applications.


    Form factor & connectors


    The term "form factor" refers to the standardized size and shape (or footprint ) of the optic, but other design features also help create each standard's definition. While there are many different transceiver form factors to consider, a few standards are more universal than the others.


    Which you need is primarily determined by what form factors are compatible in the switch or router the optic is to be plugged in to, so it is always good to check what your system accepts.


    AddOn's SFP-10G-SR-S-AO Cisco Compatible 1G SFP+ 40km LC Transceiver


    Without the right form factor for your network environment, the optic may not fit into your switch or router at all. If it does connect, it may have impaired performance.


    Can I use 100G QSFP28 port based with 40G QSFP+ transceiver?


    Most Switches, Network Packet Broker (NPB), and other Network Element allow the use of 40G QSFP+ optics within QSFP28 slot to support 10G using fanout/Breakout cable or 40G Multimode straight conectivity using MTP to MTP fiber cable.


    SFP vs SFP+ vs XFP vs QSFP+ vs CFP vs QSFP28 Differences


    Through the above definitions of each type of fiber optic transceiver module, you may have a further understanding of them. Now, we are comparing these transeiver one by one.


    SFP vs SFP+ (SFP+ vs SFP): Simple to understand, SFP+ is an updated vision of SFP. SFP usually support 1.25Gbit/s to 4.25 Gbit/s while SFP+ supports data rates up to 10 Gbit/s. When it comes to SFP vs SFP+, they have the same size and appearance, but in a different standard which SFP is based on IEEE802.3 and SFF-8472.


    SFP+ vs XFP (XFP vs SFP+): In comparison to earlier XFP modules, SFP+ modules leave more circuitry to be implemented on the host board instead of inside the module. The size of SFP+ is smaller than XFP, thus it moves some functions to motherboard, including signal modulation function, MAC, CDR and EDC. XFP is based on the standard of XFP MSA while SFP+ is compliance with the protocol of IEEE 802.3ae, SFF-8431, SFF-8432.


    SFP+ vs QSFP+: QSFP+ has four-channel SFP+ interfaces which can transfer rates up to 40Gbps. And of course, they have different standards.


    CFP vs QSFP+: QSFP+ (Quad Small Form-Factor Pluggable Plus) modules offer customers a wide variety of high-density 40 Gigabit Ethernet. The CFP is a hot-pluggable transceiver module form factor that supports a wide range of 40Gb/s and 100Gb/s applications such as 40G and 100G Ethernet.
